Author Topic: Diamondback  (Read 102552 times)

0 Members and 4 Guests are viewing this topic.

rob_maze83

  • Guest
Re: Diamondback
« Reply #50 on: March 17, 2009, 08:29 PM »
my 82 turbo...been told its the oldest recorded (survivor) from os-db
enjoy






neiljonarcus

  • Guest
Re: Diamondback
« Reply #51 on: April 07, 2009, 01:49 PM »
 HARRY LEARY  TURBO  GEN  1

Frame: 4130 chromoly
Forks: 4130 chromoly (Double Butted)
Handlebars: 4130 chromoly, (custom bend)
Stem: Diamond Back (by Sugino) Alloy clamp with chromoly shaft
Grips: Oakley F-1
Headset: Tange MTX, Black Chrome
Rims: Araya 7x, Aluminium
Spokes: Asahi 36/.080 Double Butted, Chrome plated, Black alloy nipples
Hubs: Suzue sealed bearings, low flange
Tyres: COMP 3 MITSI , 2.125 front, 1.75 rear
Brakes:Dia-Compe 890, front and rear (chrome plated)
Levers: Dia-Compe Pre Bent (polished) - Later Tech III
Cable: Dia-Compe
Pedals: Diamond Back (by SR) SR-MP 133/134 (Chrome Plated)
Crank: Diamond Back Turbo, Three piece Chromoly,  181mm
Bottom Bracket: Sugino sealed bearing
Chainring: Sugino aluminium 44T (5mm width)
Spider: Sugino, alloy (integral part of crankset)
Freewheel: Suntour, 16T
Chain: DID 3/32"
Seat: Diamond Back Turbo ("five gold" by Kashimax), suede
Seat Post: SR, aluminium (polished)
Seat Post Clamp: SR, aluminium (polished)






Juju

  • Guest
Re: Diamondback
« Reply #52 on: April 26, 2009, 02:34 PM »
Diamond Back Silver Streak (Work in progress).

Found in small ads for £100. FRame, forks, stem, bars, seatpost, 1pc crank were saved. Brakes, seatclamp, spider, chainring, wheels tyres and grips were found and fitted.





torkertony

  • Guest
Re: Diamondback
« Reply #53 on: May 01, 2009, 01:13 PM »
My early 80's Viper - original chrome & NOS parts.




Offline meticulous

  • Berm Worm
  • ***********
  • Posts: 9509
  • Rated:
Re: Diamondback
« Reply #54 on: June 24, 2009, 07:45 PM »
R.I.P  O.M. Far short of the finish line...

louisdog

  • Guest
Re: Diamondback
« Reply #55 on: October 05, 2009, 08:40 PM »

My 1983 Viper all original apart from wheels and pedals.

My 1984 Harry Leary Turbo, nearly finished.

jase1

  • Guest
Re: Diamondback
« Reply #56 on: November 08, 2009, 12:18 AM »
My Newly built 1982 Silver Streak. Not going for authenticity here, just rebuilding my 80's ride. Need a better crank though.



Anyone know who does repro padsets?

halsencrew

  • Guest
Re: Diamondback
« Reply #57 on: November 11, 2009, 04:43 AM »
mine




Offline Hurricane1

  • Curb Endo
  • **
  • Posts: 166
  • Goin flat out critical in the 80's
  • Rated:
Re: Diamondback
« Reply #58 on: November 27, 2009, 09:34 PM »
1982 Silver Streak II


Offline jT Racing

  • BMX Overlord
  • ***********
  • Posts: 17338
  • i like bikes. :/
  • Rated:
Re: Diamondback
« Reply #59 on: December 06, 2009, 05:35 PM »
81 junior pro
ding dong

Offline phantom photon

  • Cherry Picker
  • ****
  • Posts: 1049
  • Rated:
Re: Diamondback
« Reply #60 on: February 08, 2010, 01:15 PM »
1983 Diamond Back Silver Streak














Spec:

Dimond Back Silver Streak Frame and Forks
Diamond Back stamped bars
FI type grips
Suntour Stem
Tange Headset
Dia Compe 890 calipers with DC pre-bent levers
Aero Seat
Fluted Seatpost
SR Seat Clamp
Sugino Crank
Sugino Spider and Chainring
Tioga Beartrap bottom bracket
Izumi Chain
Shimano Freewheel
MKS Pedals
Skyway Tuff II Wheels
Comp III type tyres
Firebird Steve Repro Padset

foolsgold

  • Guest
Re: Diamondback
« Reply #61 on: March 16, 2010, 03:00 PM »
83 Silver Streak













lucky1

  • Guest
Re: Diamondback
« Reply #62 on: May 23, 2010, 04:31 PM »








Offline Macmania

  • Flip-Whip
  • ******
  • Posts: 2030
  • Rated:
Re: Diamondback
« Reply #63 on: May 28, 2010, 07:18 PM »
1983 Diamond Back Silver Streak
Diamond Back Silver Streak Frame and Forks, Diamond Back Stamped Bars, F1 Style Grips, SR MS-422 Stem, Tange Headset, Dia Compe MX 900 with Tech III Lever, Kashimax MX Seat, Fluted Seatpost, SR Seat Clamp, Sugino Crank, Sugino Spider and Chainring, Izumi Chain, Shimano Freewheel, MKS Pedals, Araya 7X's Wheels, Tioga Comp IIIs, Repro Padset






Wanted: Anything MT Racing

Juju

  • Guest
Re: Diamondback
« Reply #64 on: August 24, 2010, 02:44 PM »


Not entirely original, as the bars are DB Pro bars, and I went red/black rather than all black finishing trim to match the decals.

Also skyways rather than Araya's fitted, as the black/red balance of tyres pleased me!


Offline kungfunky

  • Team Moderator
  • Tail Whip
  • *
  • Posts: 5901
  • Rated:
Re: Diamondback
« Reply #65 on: November 04, 2010, 09:46 AM »
This is my 1980 DB pro, I decided to try and start racing OS again and wanted something to thrash around and found this frame set. It was a real state so had to be stripped back and there it sat for months untill I decided to get it built up. I thought making it into a HLT type replica would look pretty cool racing OS meets and she sure does get some attention. Just a shame my riding doesnt.!.  :buck2:



« Last Edit: November 04, 2010, 09:51 AM by kungfunky »
WANTED....FRED BLOOD QUADANGLE FRAME..

townslo

  • Guest
Re: Diamondback
« Reply #66 on: November 21, 2010, 02:56 AM »
My 24" Diamond Back Build! Where do you guys get the Diamond Back Pad sets, I can't find any at a decent price?





]



« Last Edit: November 21, 2010, 02:58 AM by townslo »

Shiner

  • Guest
Re: Diamondback
« Reply #67 on: January 02, 2011, 12:30 PM »
Diamondback Viper






sid1972

  • Guest
Re: Diamondback
« Reply #68 on: February 22, 2011, 02:55 PM »
db F1 - Totally original!

well ok maybe not grips.  :D

in the process and of a strip and clean, will update pics when its completed.





After a bit of  light resto:





still got the original F1 stickers on the rims  :smitten:

Hope you like it,

Sid.  :daumenhoch:

« Last Edit: April 06, 2011, 12:19 PM by sid1972 »

wired

  • Guest
Re: Diamondback
« Reply #69 on: March 01, 2011, 10:24 PM »
Well, this Diamond Back won't match any here.  My 1993 Turbo is almost finished...  :P




Offline rollin72

  • 900 Air
  • ********
  • Posts: 3497
  • I was a ninja
  • Rated:
Re: Diamondback
« Reply #70 on: May 07, 2011, 09:48 AM »
1980 Large Pro













skyway_ta

  • Guest
Re: Diamondback
« Reply #71 on: July 11, 2011, 03:00 PM »

Specifications
Lifecycle: 1979 to 1981
Frame
4130 Chromoly DiamondBack Large Pro
Fork
4130 Chromoly Dual Position (leading axle and centerline) (Koizumi)
Handle Bar
Daimond back Harry Leary Bars
Stem
Nos Sugino
Gribs
OGK
Seat
NOS Daimond back (Kashimax)
Seat Clamp
NOS Suntour
Brake Caliper
NOS MX-1000
Crank
NOS SUGINO maxy cross
Pedals
NOS BM-10 (MKS)
Chain
Izumi
Rims
NOS ARAYA
Hubs
NOS SUNTOUR
Freewheel
SUNTOUR
Tires
KENDA






Clean

  • Guest
Re: Diamondback
« Reply #72 on: July 11, 2011, 03:31 PM »
* 1980 Diamond Back Pro Large finished in Nickel (Koizumi Baseball Stamped)
* Diamond Back Dual Drop Out Forks (Koizumi Baseball Stamped)
* Diamond Back Oversize Stamped Chro-Mo Bars
* A'me Rounds
* Sugino Stem (rare "Sugino" stamped clamp)
* Tange MX2 Headset
* Tange Lock Nut
* Dia Compe 890s wearing Dia Compe Pads
* Dia Compe Pre Bent Levers
* Dia Compe Cables & Cable Clips
* Sugino Mighty Competition Cranks
* MKS BM7s
* KMC Chain
* Sharp BB Boot
* Araya 7X laced to Sunshine Hubs wearing Comp IIIs
* Suntour Freewheel
* Alloy Dropout Savers
* Suntour Alloy Wheel Nuts
* Fluted Red & Silver Alloy Post
* Kashi Aero Copy Seat
* Suntour "Arrows" Post Clamp
* Repro Cali-Lite Pads courtesy of our very own Firebird
* Bucket loads of care, attention & elbow grease
* Unquantifiable love and pride















« Last Edit: August 27, 2011, 10:20 PM by Clean »

Offline rollin72

  • 900 Air
  • ********
  • Posts: 3497
  • I was a ninja
  • Rated:
Re: Diamondback
« Reply #73 on: September 07, 2011, 12:16 PM »
1981 mini pro frame and forks
Robinson mini bars
mini ame duals
DC 730 calipers and DC tech3
sr stem
velo mini seat with uni cover
suntour seatclamp
TA mini cranks
ttk pedals
ukai 1 3/8 rims on sr large flange hubs
yellow label comp3's 1 3/8

















nice1 Gaz :daumenhoch:




elevensies

  • Guest
Re: Diamondback
« Reply #74 on: January 06, 2012, 09:33 PM »
is this allowed?
my daughters 2001 expert from when she used to race




my sugino cranks though lol
