First foray into derusting with Oxalic Acid
« on: April 18, 2011, 09:07 PM »
OK, peeps.... sharing yesterday's experience with some OA and very hard to reach rust (inside tubes, inside dropout welds etc.)

Mixed it rich (250grams to 4 litres water) and soaked for 30 minutes.

Water turned yellow (think morning after urine) and rust turned whiteish before disappearing.

Thorough rinse in cold clean water for a good while then into the sun to dry out for an hour or so.

I did end up with some tide marks on the chrome / nickel and the odd strange blemishes which I suspect relate to the quality of the rework the Frameset had before I got it. Some Peek and elbow grease soon put paid to those, though.

Now to treat the internals with ACF-50 and we are ready to build.

Sorry there are no pics; due to the location of all of the rust the "Before"s didn't turn out very well.

Still, I can confirm it works, and that any blemishes can be worked out with Peek. I probably would mix it leaner next time around, though, as the fumes were a bit heady!

Offline wildon

  • Flip-Whip
  • ******
  • Posts: 2105
  • Rated:
Re: First foray into derusting with Oxalic Acid
« Reply #1 on: April 18, 2011, 09:14 PM »
it's just a big anti-climax without pics  :P

Offline Jaymz

  • Team RAD
  • My life is Radbmx
  • *
  • Posts: I am a geek!!
  • I'm not FOOKING Dave
  • Rated:
Re: First foray into derusting with Oxalic Acid
« Reply #2 on: April 18, 2011, 09:18 PM »
have you done this to the dyno fella?

Clean

  • Guest
Re: First foray into derusting with Oxalic Acid
« Reply #3 on: April 18, 2011, 09:23 PM »
have you done this to the dyno fella?

No, mate... that went straight to a mate at work for his kid.

I am working on a 1980 DB Pro Large!  :smitten:

it's just a big anti-climax without pics  :P

I know, that's why I said sorry!!! TTIUWP  :'(

Offline Jaymz

  • Team RAD
  • My life is Radbmx
  • *
  • Posts: I am a geek!!
  • I'm not FOOKING Dave
  • Rated:
Re: First foray into derusting with Oxalic Acid
« Reply #4 on: April 18, 2011, 09:28 PM »
sounds tasty, we definately need a more visual story of the build though fella otherwise i will chase you round the forum posting this


Clean

  • Guest
Re: First foray into derusting with Oxalic Acid
« Reply #5 on: April 18, 2011, 09:32 PM »
Will get some up on a new T&R Build Thread as soon as I have amassed the parts and am ready for an assembly!  :daumenhoch:

griff

  • Guest
Re: First foray into derusting with Oxalic Acid
« Reply #6 on: April 18, 2011, 11:22 PM »
^^^ what they said about pics

mate what did you use to soak the frame in? been looking for a suitable (and cheap) container as for some reason my wife thinks that trying to make an acid bath using a bin bag and a cardboard tray is a bad idea. nearest thing I found was some underbed storage box but that wasn't exactly cheap


Offline oldtired

  • 540 Air
  • *******
  • Posts: 2533
  • Dirty Old Man
  • Rated:
Re: First foray into derusting with Oxalic Acid
« Reply #7 on: April 19, 2011, 12:22 AM »
square frame made of wood and some wheely bin liners  :daumenhoch:

Clean

  • Guest
Re: First foray into derusting with Oxalic Acid
« Reply #8 on: April 19, 2011, 12:42 PM »
I used a bucket for one end, and then the kitchen sink (the missus was at work) for the other.

Anything made of plastic, porcelain or glass, should be fine.

Clean.

trasher

  • Guest
Re: First foray into derusting with Oxalic Acid
« Reply #9 on: April 27, 2011, 06:18 PM »
^^^ what they said about pics

mate what did you use to soak the frame in? been looking for a suitable (and cheap) container as for some reason my wife thinks that trying to make an acid bath using a bin bag and a cardboard tray is a bad idea. nearest thing I found was some underbed storage box but that wasn't exactly cheap




i used the kids little paddling pool   >:D


Offline Peter J

  • BMX Nerd
  • *********
  • Posts: 4993
  • I have issues
    • http://www.sumoservices.com/
  • Rated:
Re: First foray into derusting with Oxalic Acid
« Reply #10 on: April 27, 2011, 06:23 PM »
^^^ what they said about pics

mate what did you use to soak the frame in? been looking for a suitable (and cheap) container as for some reason my wife thinks that trying to make an acid bath using a bin bag and a cardboard tray is a bad idea. nearest thing I found was some underbed storage box but that wasn't exactly cheap




i used the kids little paddling pool   >:D



http://www.mothercare.com/Mothercare-Bath-Jungle-Family/dp/B0030SJT3S/280-9030555-6680444?ie=UTF8&ref=sr_1_3&nodeId=44536031&sr=1-3&qid=1303924944&pf_rd_r=1CDXENKFAXNZB06N36TW&pf_rd_m=A2LBKNDJ2KZUGQ&pf_rd_t=101&pf_rd_i=44536031&pf_rd_p=231490867&pf_rd_s=related-tab-3-5
I might actually build a bike this year instead of just hoarding parts :)

Offline Betty

  • 900 Air
  • ********
  • Posts: 3141
  • Rated:
Re: First foray into derusting with Oxalic Acid
« Reply #11 on: April 27, 2011, 07:46 PM »

i used the kids little paddling pool   >:D



Awesome...  ;D
2 minutes turkish...
